Regulated gene:trpE
| Direction | - |
|---|---|
| Start position | 2375110..2376657 |
| Operon | trpEDCFBA |
| Transcription start site | |
| COG ID | COG0147 |
| Profile | anthranilate synthase |
| Binding factor |
Regulation | Location | Absolute position | Binding seq.(cis-element) | Exp. | Reference | Year |
|---|---|---|---|---|---|---|---|
| SigA | ND | ND | 2376801..2376920 | GTCCCTCAGGATCAGATCAGACATGTATATTTA GAAAAAGTTGTCGTATTGAGGCCCGATTTATCATTGACAAAAAAT--A CTGAATTGTAATACGATAAGAACAGCTTAGAAATACACAAG |
S1 | Shimotsu H,et al. | 1984 |
| TraP | ND | ND | 2376728..2376783 | TAGAATGAGTTGAGTTAGAGAATAGGGTAGCAGAGA ATGAGTTTAGTTGAGCTGAG |
ND | Babitzke, P., et al. | 2001 |
| TraP | Positive | +69:+78 | 2376731..2376760 | AGGGTAGCAGAGAATGAGTTTAGTTGAGCT |
DP HB | Kuroda MI, et al. | 1988 |
Alignment Result: Bacillus genera
